100V line mixer-amp with digital amplifier in a compact housing. An onboard audio player accepts USB media for digital audio or can be tuned to FM radio stations. In Bluetooth mode, a smart phone or tablet may be paired with the DM25 for wireless audio playback. Mono output to either 100V line or 4-16 ohms speaker load is connected via spring terminals on the rear panel. All-in-one solution for small sound installations.
Bluetooth connectivity Integral USB player and FM tuner 100V line or 4-16 Ohms operation Note: USB port is not for charging smart phones
Power supply 230Vac, 50Hz (IEC) Speaker : outputs COM, 100V and 4-16 Ohms (spring terminals) Audio source USB player, FM tuner and Bluetooth receiver Bluetooth version V2.1 Controls Treble, Bass, MP3, Aux, Mic Microphone : inputs 6.3mm jack (unbalanced) Line input 2 x RCA (summed to mono) Line output 2 x RCA Antenna connection Spring terminal Dimensions 280 x 205 x 67mm (L x W x H) Fuse T1AL 230V USB version USB 2.0 (FAT32, 128GB max.)
